CellClutch Connect - Cordless Electric - Pistol & Right Angle

CellClutch® Cordless Assembly Tools deliver simple, programmable torque control to your line.

Features

  • Reduced Operator Error - Pre-set torque, "ok" "not ok" green and red lights make tool operation simple.Eliminate cross threads and errors during rundowns with programmable speeds and strategies.
  • Eliminate Over Torque Damage - Contactless electronic switch shuts off tightening rotation when set torque is reached.
  • Reliable Single Battery Platform - Milwaukee® M18 Red Lithium battery can be used across the entire Cleco cordless range to reduce complexity and costs in your plant.
  • WiFi (2.4 & 5 GHz) and Bluetooth v4.2 (Low Energy and BR/EDR) wireless communication for easy-to-program setting adjustments, live reporting, traceability, and batch counting through the mPro controller platform.*Available in Connected version only, mPro Controller sold separately*Bluetooth is a registered trademark owned by Bluetooth SIG, Inc.
  • Speed Control - Easily change the tool's RPM settings to meet the required application requirements.
  • Ergonomic - Lightweight, cordless design eliminates the need for bulky cords and hoses.
  • Improved Visibility - Built-in LED worklight illuminates the work surface to reduce strain.
  • Software Included At No Extra Charge - Reduce total cost of ownership with CellClutch software included with tool purchase.
  • Accuracy – CM > 1.67 within a +/- 10% tolerance range
  • Note: Connected tools are region-specific. To avoid Wi-Fi or connectivity issues, make sure to order the correct model number for the region where the tool will be used.

Product Information

Compare S.No Model Style Torque Range MinTorque Range MaxFree SpeedWeightLengthSide to Center
Nm Nm 1/min kg mm mm
CLBPW04Q-CNPistol1.14.015001.121829
CLBPW08Q-CNPistol2.18.09851.129
CLBPW12Q-CNPistol3.212.07001.121829
CLBAW653-EURight Angle15.965115252619
CLBAW653-NARight Angle15.965115252619
CLBAW653-CNRight Angle15.965115252619
1CLBAW403-00Right Angle15.1411851.951418.5
1CLBPW12Q-00Pistol3.212.07001.121829
10CLBAW203-NARight Angle8.3213601.849315.0
11CLBPW04Q-EUPistol1.14.015001.121829
12CLBAW203-EURight Angle8.3213601.849315.0
12CLBPW04Q-NAPistol1.14.015001.121829
13CLBAW123-00Right Angle3.3126501.545312.5
14CLBAW123-NARight Angle3.3126501.545312.5
16CLBAW123-EURight Angle3.3126501.545312.5
17CLBAW083-00Right Angle2.289151.545312.5
18CLBAW083-NARight Angle2.289151.545312.5
2CLBAW403-NARight Angle15.1411851.951418.5
20CLBAW083-EURight Angle2.289151.545312.5
3CLBPW12Q-EUPistol3.212.07001.121829
4CLBAW403-EURight Angle15.1411851.951418.5
4CLBPW12Q-NAPistol3.212.07001.121829
5CLBAW303-00Right Angle8.3302551.849315.0
5CLBPW08Q-00Pistol2.18.09851.121829
6CLBAW303-NARight Angle8.3302551.849315.0
7CLBPW08Q-EUPistol2.18.09851.121829
8CLBAW303-EURight Angle8.3302551.849315.0
8CLBPW08Q-NAPistol2.18.09851.121829
9CLBAW203-00Right Angle8.3213601.849315.0

Note: Connected tools are region-specific. To avoid Wi-Fi or connectivity issues, make sure to order the correct model number for the region where the tool will be used.NA=North America, EU=Europe, CH=China; 00=Rest of World
